CFL LiQiFlowS®
Engineered for superior performance, CFL LiQiFlowS® filter cartridges combine advanced filtration technology with robust construction to meet the most demanding process requirements.
Utilising high-efficiency glass fibre or polypropylene filter media, each cartridge is thermally bonded into durable polypropylene hardware, ensuring exceptional chemical compatibility and structural integrity.
Key features and benefits
High Efficiency
BETA 5000 (99.98%) efficiency for reliable particle removal.
Absolute Rating
Available in absolute ratings from 1 to 70 microns for precise particulate control.
Excellent Chemical Compatibility
Compatible with a wide range of chemicals, making it ideal for diverse industrial applications.
High Throughput
Optimised pleat pack design minimises pressure drop and maximises flow rates.
Long Service Life
High dirt holding capacity for extended service life and reduced operating costs.
Low Pressure Drop
Minimises energy consumption.
Robust Construction
Thermally bonded construction eliminates the need for adhesives, minimising extractables and ensuring cartridge integrity.
Versatile Options
Available in various lengths (10″ to 40″) and with a variety of end connections to suit most standard housings.
High Dirt Holding Capacity
Efficiently captures contaminants, extending service life and reducing downtime and maintenance frequency.
Superior Chemical Resistance
Resistant to a wide range of chemicals, making LiQiFlowS ideal for diverse industrial applications.
Applications
Product specifications
Filtration media:
Polypropylene, Glass Fibre
Glass support:
Polypropylene
Polypropylene support:
Polypropylene
Inner support core:
Polypropylene
Outer protection cage:
Polypropylene
Endcaps:
Polypropylene, Nylon and Stainless Steel
Standard O-rings/Gaskets:
Nitrile, EPDM, Silicone, Viton
Effective filtration area
Polypropylene:
Up to 0.55 m² per 250 mm module
Glass fibre:
Up to 0.48 m² per 250 mm module
Technical specifications
Filtration media:
FDA-approved Glass Fibre or Polypropylene
Drain layers:
FDA-approved Glass Fibre or Polypropylene
Hardware:
FDA-approved Polypropylene
Filter efficiency:
99.98% in liquids (as established by standard OSU-F2 particle test using AC Fine/Coarse test dust)
Recommended operating conditions
Maximum operating temperature:
85°C (185°F)
Maximum differential pressure:
5.5 barg (80 psid)
Recommended changeout pressure:
2.5 barg (36 psid)
